- Economical drill with good chip control due to optimal chip flute enlarging the space for chip flow
- Stable machining due to optimal shape and cutting edge arrangement of central and peripheral inserts
- Reduced production cost
- Economical drill with good cutting performance
- Excellent chip control and surface finish
- Optimized chip breakers for various workpiece types
- Stable machining
- A set of diversely shaped central and peripheral inserts
- High resistance to chipping and wear
- Various grades for different kinds of workpiece
| Indexable Drills | |
|---|---|
| TPDB Plus Drill | King Drill |
| TPDB-F | King Drill (for through coolant system with a lathe) |
| TPDB-H | King Drill (for large diameter drilling) |
| Technical information for WPDC | KED Plus Drill |
| Brazed Carbide, HSS Center Drills | TPDC Plus Drill |
| WPDC | |
DRILLS - Korloy drills provide a total solution for hole making, based on tooling know-how as well as extensive research and development for our tools.
| Types | Designation | Shapes | Drill Dia. | Aspect ratio |
|---|---|---|---|---|
| Indexable Drills |
King Drill K_D | Available insert: SPMT, XOMT | Ø12.0~Ø60.5 | 2D~5D |
| King Drill HP K_D..HP | Available insert: SPMT, XOMT | Ø12.0~Ø60.5 | 2D~4D | |
| King Drill (for large diameter drilling) K_D | Available insert: SPMT, XOMT | Ø61.0~Ø100.0 | 2D~4D F | |
| KED Plus Drill E_D | Available insert: SPMT, XOMT | Ø12.0~Ø60.5 | 2D~5D | |
| TPDC Plus Drill - TPDX | Available insert: TPD▫▫▫▫XP |
Ø8.0~Ø11.9 | 3D~8D | |
| TPDC Plus Drill - TPDC | Available insert: TPD▫▫▫▫C | Ø12.0~Ø30.9 | 1.5D~12D | |
| TPDB Plus Drill - TPDB-P | Available insert: TPD▫▫▫B | Ø10.0~Ø32.9 | 3D~12D | |
| TPDB Plus Drill - TPDB-F | Available insert: TPD▫▫▫B-F | Ø14.0~Ø30.9 | 1.5D | |
| TPDB Plus Drill - TPDB-H | Available insert: TPD▫▫▫B-H | Ø14.0~Ø30.9 | 3D~8D | |
| Indexable Drills & Drill with center - WPDC |
Available insert: WC▫T | Ø25.0~Ø80.0 | 5D~8D |
